Dust Sampler

About Dust Sampler

Dust Sampler Apm 860

Our company is successfully expanding in the market by manufacturing and exporting an excellent range ofDust Samplers. These samplers are widely used for testing the dust present in the air. Manufactured under the direction of senior professionals using tested quality materials and advance techniques, these samplers are highly demanded in the market for their best performance. The offered samplers are tested on various safety parameters to ensure their flawless range. We offer these Dust Samplers at economical rate.

Features:

• Easy to operate
• High functionality
• Sturdy construction

Special features:

• Brushless blowerreduces equipment downtime and maintenance effort.
• Lockablecasters and gaseous attachment.
• Improved cabinet design which ismore sturdy and durablewith SS hardware.
• Brushless blower reduces equipment downtime and maintenance efforts
• Significantly reduce Noise

APM 860 comes withan in-built voltage stabilizer to compensate for voltage fluctuations. This model has been made more user-friendly, tool box within the instrument, softer handles.

Owing to its modular design, APM 860 can be easily paired with a gaseous sampling attachment (for monitoring SO2, NOx, NH3, Ozone etc.)as gaseous sampling requires only a few LPM of air flow. This is possible through anattachable subsidiary unit LES 411. Kindly refer to respective brochures of LES 411.

Specification:

• Flow Rate:0.9 -1.4 m3 /min free flow
• Particle Size: Particles of 10 microns & below collected on Filter Paper holder. SPM bigger than 10 microns collected in a separate sampling bottle under the cyclone
• Sampling Time: 28 hours (maximum)
• Sampling Time Record: 0 to 9999.99 hrs. recorded on a Time Totalizer
• Power requirement: Nominal 220 V, Single Phase, 50Hz AC mains supply. For proper operation and safety a good earth connection is mandatory
• Size & Weight: 420 x 340 x 790 mm, 40 Kg
• Automatic Sampling: 24 hrs programmable timer to automatically shut off the system after pre-Control set time interval.
• Warranty: One year

Specification

Weight	40 Kg
Type	Portable
Material	Steel
No of Wheels	Four
Warranty	One year
Size	420 x 340 x 790 mm
Power	220 V

Reliable Dust Sampling for All Environments

This sampler is suited for air quality monitoring in both indoor and outdoor settings. Equipped with two sampling heads, it can collect dust particles simultaneously, which enhances sampling accuracy. Its compliance with IS 5182, Part IV standards ensures output reliability for a wide range of environmental studies and industrial applications.


Efficient and Portable Design

Crafted from lightweight aluminium, the dust sampler features a carry handle and a strap for enhanced mobility. Its power-efficient operation and low-maintenance build mean you spend less time on upkeep and more on actual sampling. The included accessories make setup and operation straightforward, wherever environmental measurements are needed.


Manual Data Collection and Flexible Accessories

Manual data output allows users to directly retrieve and analyze collected samples for dust concentration. The sampler comes with all necessary componentsfilter holders, tubing, and strapsso you can quickly start sampling at any location, without complicated preparation.
